Fire Extinguisher Ball Drone

Fire Extinguisher Ball Drone

This is a professional industrial fire-fighting drone designed specifically for firefighting and emergency rescue. It has a maximum payload of 65 kg and its fuselage is constructed from aerospace-grade aluminum alloy and carbon fiber, ensuring higher strength, hardness, toughness, and fatigue resistance.
Send Inquiry
Description
Technical Parameters
2

This is a professional industrial fire-fighting drone designed specifically for firefighting and emergency rescue. It has a maximum payload of 65 kg and its fuselage is constructed from aerospace-grade aluminum alloy and carbon fiber, ensuring higher strength, hardness, toughness, and fatigue resistance. It can withstand extreme working conditions encountered during flight and supports partial functional customization.

This fire-fighting drone is fearless in harsh environments, possessing industrial-grade waterproof, dustproof, and corrosion-resistant capabilities. It can adapt to various demanding conditions, has relatively low maintenance costs, and a longer service life. With strong anti-magnetic interference capabilities, it can maintain stable flight even in complex environments such as near high-voltage power lines. Its operating temperature range is -10℃ to 40℃. Its foldable fuselage design, electric drive, and long endurance make it suitable for a variety of challenging operations, such as forest firefighting, industrial area firefighting, residential area firefighting, power line inspection, reservoir inspection, and law enforcement operations.

This fire-fighting drone is equipped with a 2K high-definition 30x hybrid zoom gimbal camera, providing a field of view of over 100 meters. Its fast and accurate algorithms, combined with the upgraded MK15 smart remote controller and built-in app, free you from the clutter of information on ordinary mobile devices. It supports various pod attachments, including a six-way delivery kit, and is equipped with dry powder fire extinguishing balls for large-scale firefighting operations. Two 18S-40000mAh batteries eliminate the need for frequent replacements, saving time and improving high-altitude operation efficiency. It also features one-key return-to-home, return-to-home in case of failure, flight path planning, and point-and-click flight functions for enhanced flight safety.



Key Specification



Model No.

ZK-F135

Material

aerospace aluminum + carbon fiber

Folded size

150*135*112cm

Max take-off weight

135kg

Wheelbase

260cm

Max flight speed

15m/s

Drone weight

42kg

Max payload

65kg

Standard payload

50kg

Flight control

dual IMU backup GNSS

Propeller

56-inch

Working temperature

-10℃-50℃



key specification



Product Advantages



1.Support partially customized service on specifications.
2.One-to-one online WeChat group service according to actual operation requirements
3.Wide Application Field: mapping, emergency search and rescue, power inspection,material transportation,Police law enforcement, fire rescue and other fields of operation
4.The product is modular and designed for overseas projects, can be shipped in individual parts, allowing overseas customers to easily install it upon receipt.
5.Long Endurance : Full load up to 30 minutes, no load lasts 80 minutes
6.Multiple camera for options,real time data
7.Route setting to achieve autonomous flight,hand-free and worry-free
8.Support Multiple Pod Mounts : fire launcher,dry powder fire ball,descent control device,multiple-channel thrower,onboard type 95 mounting bracket,delivery box,38MM transmitter,red and blue flash,and etc, different mountings,different mounts can be installed to achieve different functions to adapt to different application scenarios and fields.
9.Drone Parts & Accessory Support : we can provide all related parts and accessories for fire fighting uav upon request.

product advantages



Technical Support & After-Sales Service



technical support and after sales service

1.Free replacement provided within warranty period for non-human caused damage if any defects been found after the receipt of the drone
2.Practical Training course provided upon request and issue CAAC certificate
3.Tutorial working video provided upon request for this fast food drone delivery.
4.Dedicated after-sales online WeChat group for technical communication support.



Application



Our Logistics drones are widely used for serving both the following urban and rural areas.

Customer Attributes

Target Customers

Application Scenarios

government and public safety agencies

fire and rescue corps/brigade, emergency management department, forest Fire brigade, public security bureau

Urban High-Rise/Special Fires 2.Forest and Grassland Fires

3.Geological Disaster Relief

specific high-risk industries

petrochemical companies, power grid companies, large industrial parks, and forestry units

Industrial Facility Inspection and Monitoring

Industrial Fire Emergency Response

professional rescue and service organizations

commercial rescue companies, drone service companies, smart city operators

Comprehensive Emergency Rescue Services

Smart City and Community Security



application scenarios



Package Include



  • 1.Dry Powder Fire Ball UAV *1
  • 2.Remote control*1
  • 3.High-speed dual-channel charger*1
  • 4.10x optical zoom lens*1
  • 5.Semi-solid battery*2
  • 6.Rope descender*1
  • 7.Fire extinguishing bomb *6
  • 8.Flight case*1



FAQ



Q: Are Chinese firefighting drones real?

A: Yes, our fire fighting drones has been widely used in domestic country and overseas countries

Q: How do fire extinguisher balls work?

A: We have the video to show your how does the drone work, please contact us for details.

Q: What is the involvement of drone technology and fire-extinguishing balls in firefighting?

A: Drones equipped with thermal infrared detectors can detect the heat on the surface above a fire source.

Q: Is the fire extinguishing bomb powder or liquid status?

A: We have both the liquid type and powder type, it's up to customers' demands.
